Signature Digital Pakai Canvas

tech

Table of Content

• Introduction
• Load CSS dan JS
• JS nya
• CSS nya
• Blade nya
• Logic JS nya
• Logic PHP nya

Introduction

Studi kasus kali ini saya disuruh buat tanda tangan digital menggunakan canvas alias langsung dari web tanpa upload foto.

Source Code : https://codepen.io/yguo/pen/OyYGxQ

Load CSS dan JS

<link href="{{ asset('assets/css/signature-pad.css') }}" rel="stylesheet" type="text/css" />
<script src="{{ asset('assets/js/signature-pad.js') }}"></script>

JS nya

(function() {
    window.requestAnimFrame = (function(callback) {
      return window.requestAnimationFrame ||
        window.webkitRequestAnimationFrame ||
        window.mozRequestAnimationFrame ||
        window.oRequestAnimationFrame ||
        window.msRequestAnimaitonFrame ||
        function(callback) {
          window.setTimeout(callback, 1000 / 60);
        };
    })();

    var canvas = document.getElementById("sig-canvas");
    var ctx = canvas.getContext("2d");
    ctx.strokeStyle = "#222222";
    ctx.lineWidth = 4;

    var drawing = false;
    var mousePos = {
      x: 0,
      y: 0
    };
    var lastPos = mousePos;

    canvas.addEventListener("mousedown", function(e) {
      drawing = true;
      lastPos = getMousePos(canvas, e);
    }, false);

    canvas.addEventListener("mouseup", function(e) {
      drawing = false;
    }, false);

    canvas.addEventListener("mousemove", function(e) {
      mousePos = getMousePos(canvas, e);
    }, false);

    // Add touch event support for mobile
    canvas.addEventListener("touchstart", function(e) {

    }, false);

    canvas.addEventListener("touchmove", function(e) {
      var touch = e.touches[0];
      var me = new MouseEvent("mousemove", {
        clientX: touch.clientX,
        clientY: touch.clientY
      });
      canvas.dispatchEvent(me);
    }, false);

    canvas.addEventListener("touchstart", function(e) {
      mousePos = getTouchPos(canvas, e);
      var touch = e.touches[0];
      var me = new MouseEvent("mousedown", {
        clientX: touch.clientX,
        clientY: touch.clientY
      });
      canvas.dispatchEvent(me);
    }, false);

    canvas.addEventListener("touchend", function(e) {
      var me = new MouseEvent("mouseup", {});
      canvas.dispatchEvent(me);
    }, false);

    function getMousePos(canvasDom, mouseEvent) {
      var rect = canvasDom.getBoundingClientRect();
      return {
        x: mouseEvent.clientX - rect.left,
        y: mouseEvent.clientY - rect.top
      }
    }

    function getTouchPos(canvasDom, touchEvent) {
      var rect = canvasDom.getBoundingClientRect();
      return {
        x: touchEvent.touches[0].clientX - rect.left,
        y: touchEvent.touches[0].clientY - rect.top
      }
    }

    function renderCanvas() {
      if (drawing) {
        ctx.moveTo(lastPos.x, lastPos.y);
        ctx.lineTo(mousePos.x, mousePos.y);
        ctx.stroke();
        lastPos = mousePos;
      }
    }

    // Prevent scrolling when touching the canvas
    document.body.addEventListener("touchstart", function(e) {
      if (e.target == canvas) {
        e.preventDefault();
      }
    }, false);
    document.body.addEventListener("touchend", function(e) {
      if (e.target == canvas) {
        e.preventDefault();
      }
    }, false);
    document.body.addEventListener("touchmove", function(e) {
      if (e.target == canvas) {
        e.preventDefault();
      }
    }, false);

    (function drawLoop() {
      requestAnimFrame(drawLoop);
      renderCanvas();
    })();

    function clearCanvas() {
      canvas.width = canvas.width;
    }

    // Set up the UI
    var sigText = document.getElementById("sig-dataUrl");
    var sigImage = document.getElementById("sig-image");
    var clearBtn = document.getElementById("sig-clearBtn");
    var submitBtn = document.getElementById("sig-submitBtn");
    clearBtn.addEventListener("click", function(e) {
      clearCanvas();
      sigText.innerHTML = "Data URL for your signature will go here!";
      sigImage.setAttribute("src", "");
    }, false);
    submitBtn.addEventListener("click", function(e) {
      var dataUrl = canvas.toDataURL();
      sigText.innerHTML = dataUrl;
      sigImage.setAttribute("src", dataUrl);
    }, false);

  })();

CSS nya

#sig-canvas {
	border: 2px dotted #CCCCCC;
	border-radius: 15px;
	cursor: crosshair;
}

Note : JS dan CSS cukup copas aja dari source code.

Blade nya

<div class="modal-body">
	<div class="img-container">
		<div class="row">
			<div class="col-md-8">
				<canvas id="sig-canvas" width="620" height="160"></canvas>
				<textarea id="sig-dataUrl" class="form-control" rows="5" style="display: none"></textarea>
				<p>Hasilnya : </p>
				<img id="sig-image" src=""/>
			</div>
		</div>
	</div>
</div>

Disini saya akan load canvas, url data nya dan contoh image preview ttd nya!

Logic JS nya

$('#btnSubmit').click(function(){
	var canvas = document.getElementById('sig-canvas');
	var dataUrl = canvas.toDataURL();

	$.ajax({
		url: '{{ route('master.user.signature_ttd_online') }}',
		method:'PUT',
		data:{
			signature_image: dataUrl
		},
		success:function(data)
		{
			$("#ttdDigital").modal("hide");
			window.location.reload()

			Swal.fire({
				icon: 'success',
				title: 'Berhasil',
				text: 'Tanda tangan berhasil disimpan'
			});
		},
		error: function(xhr, status, error) {
			console.error(xhr.responseText);
		}
	});
});

Penjelasan :

• Metode toDataURL() pada elemen <canvas> dalam JavaScript digunakan untuk mengembalikan representasi dalam bentuk URL data dari gambar yang dirender di dalam kanvas. Ini berguna untuk menyimpan gambar yang telah dibuat atau mengirimkannya ke server.

Logic PHP nya

public function signature_ttd_online(Request $req)
{
	$picture = $req->signature_image;

		// Maka dia png
		$extension = '.png';
	}else{
		// Maka dia jpg
		$extension = '.jpg';
	}

	$imageName = uniqid() . $extension;
	$image = str_replace(' ', '+', $image);

	User::where('id', Auth::user()->id)
			->update([
				'tanda_tangan' => $imageName
			]);

	// // Store to public folder
	\\File::put('assets/tanda_tangan/' . $imageName, base64_decode($image));

	return response()->json(['success' => true]);
}

Note : jangan lupa penggunaan base64.

Date : 31-05-2024
